NetApp 111-00569-A0 SAS CONTROLLER I/O MODULE 0948580-04

$71.40 (Ex. GST)

In stock: 1

NetApp SAS CONTROLLER I/O MODULE 0948580-04

Dual-port (or quad-port in some configs) Mini-SAS (SFF-8088) external connectors

Internal SAS expander for 24 drives

SES monitoring and LED control

Hot-swappable design (when redundant IOM present)

Status LEDs for power, link/activity, faults

Supports SAS/SATA HDDs/SSDs (3 Gbps)

Model / Part Number | NetApp 0948580-04 (IOM3 SAS I/O Controller Module)
Alternate / Related | 111-00569-A0 / 111-00569 / 111-00128+A0 / X5712A-R6
Interface / Connector Type | External: Mini-SAS (SFF-8088) / Internal: SAS expander to 24 drives
Capacity / Speed / Frequency | 3 Gbps SAS (SAS 1.0/SAS 2.0) / Controls 24 SAS/SATA drives
Form Factor | Plug-in IOM module (rear of DS4243/DS2246 shelf)
Spindle Speed (RPM) | N/A (SAS controller module)
Sector Format / Firmware Info | N/A (Hardware expander)
Power Requirements | Shelf-supplied / Typical ~20–40W (module-dependent)

NetApp SAS CONTROLLER I/O MODULE 0948580-04 2nd: 0948580-04 : Alt (111-00569-A0) (111-00128+A0) Other//

NetApp SAS CONTROLLER I/O MODULE 0948580-04 2nd: 0948580-04 : Alt (111-00569-A0) (111-00128+A0) Other//

$71.40 (Ex. GST)

$71.40 (Ex. GST)
