YJXMR DELL 2M SFF-8088 TO SFF-8644 MINI-SAS HD CABLE

$43.35 (Ex. GST)

In stock: 1

The Dell YJXMR is a 2-meter (6.56 ft) external SAS cable with SFF-8088 on one end and SFF-8644 (Mini-SAS HD) on the other. It is a genuine Dell-branded cable designed for connecting servers with older 6 Gbps SAS ports to newer 12 Gbps SAS storage enclosures or expanders (and vice versa).

This is a high-quality, shielded external SAS cable that bridges SAS-2 (6 Gbps) and SAS-3 (12 Gbps) infrastructure. It allows full backward and forward compatibility:

  • Connects a 12 Gbps SAS controller/HBA (SFF-8644 port) on a newer server to an older 6 Gbps SAS disk enclosure (SFF-8088 port), or
  • Connects an older server (SFF-8088) to a newer 12 Gbps enclosure (SFF-8644).

The cable supports up to 12 Gbps per lane (48 Gbps aggregate across 4 lanes) when both ends are SAS-3 capable. When one end is limited to SAS-2, the link negotiates down to 6 Gbps (24 Gbps aggregate) — still full performance for older enclosures.

It features premium twinaxial copper pairs, foil + braid shielding, gold-plated connectors, and a flexible yet durable jacket — engineered to maintain signal integrity over the full 2-meter length with minimal crosstalk, insertion loss, or jitter.

This cable is Dell-validated to ensure proper link training, speed negotiation, error-free operation, and correct recognition in OpenManage / iDRAC — avoiding common issues seen with generic or third-party cables (e.g., link flapping, reduced speed, or intermittent errors).

  • Model / Dell Part Number: YJXMR
  • Cable Type: External Mini-SAS HD (SFF-8644) to Mini-SAS (SFF-8088)
  • Length: 2 meters (≈6.56 feet)
  • Data Rate Support: Up to 12 Gbps per lane (SAS-3), 48 Gbps aggregate (4 lanes)
  • Backward Compatibility: Fully supports SAS-2 (6 Gbps) and SAS-1 (3 Gbps)
  • Connector A: SFF-8644 (Mini-SAS HD, host/target side – newer 12G controllers/enclosures)
  • Connector B: SFF-8088 (Mini-SAS, host/target side – older 6G controllers/enclosures)
  • Primary Use: Connecting Dell PowerEdge servers (12G/13G/14G) to external SAS disk enclosures (PowerVault MD series)
  • Status (2025–2026): Legacy / End-of-Sale – still widely used in production but no new production
  • Market Availability: Refurbished or new-old-stock from Dell parts resellers, eBay, surplus vendors
  • Typical Price Range: $40–$120 (refurbished/NOS, depending on condition)

Cable Length: 2 meters (6.56 ft)

Connector Type A: SFF-8644 (Mini-SAS HD, 36-pin)

Connector Type B: SFF-8088 (Mini-SAS, 36-pin)

Data Rate: SAS-3 12 Gbps (48 Gbps aggregate across 4 lanes)

Backward Compatibility: SAS-2 6 Gbps (24 Gbps aggregate), SAS-1 3 Gbps

Pinout: Standard Mini-SAS HD to Mini-SAS (straight-through)

Cable Construction: High-quality twinaxial shielded pairs + foil/braid shielding

Impedance: 100 ohms differential

Signal Integrity: Gold-plated contacts, low crosstalk, low insertion loss

Bend Radius: Flexible (minimum bend radius ≈25 mm)

Operating Temperature: 0°C to 70°C (commercial grade)

Jacket Material: PVC or LSZH (low-smoke zero-halogen in some variants)

Shielding: Full shielding (foil + braid) for EMI/RFI protection
